Joystick breakout module
[47023]
CHF 7.55

Product retired

This product has been retired from our catalogue and is not available for odering anymore. The page is being kept for those looking for datasheets, sample code or other information.



Stock: 0

This is a breakout module for Playstation2 analog joystick.

There are 5 pins on board: VCC, GND, X, Y and Button. Connect the module with 5V power suppy with VCC and GND, you can read out the joystick status by X,Y and button pins.

When using the 5V power supply, the defualt analog output for X,Y is 2.5V. With the direction of the arrow, the voltage up to 5V, and the opposite direction down to 0V.

This product was added to our catalog on Monday 18 July, 2011.
