Smart LED Strip RGB LPD8806 IC / SMD5050 LEDs
This RGB LED strip allows you to individually control all 180 RGB LEDs on a waterproof strip in groups of 6 LEDs (6 LEDs controller by a single LPD8806). The LPD8806 even allows you to set the PWM Level for each color with an 8 Bit resolution. Each six LEDs have their own LPD8806 IC and current limiting resistors. Unfortunately there is no datasheet for the strip but a very mature Arduino Library (see below).
Features:
- LED Type: 5050 SMD LED (Waterproof)
- Color: RGB
- LED Quantity: 36 LEDs / Meter
- IC number: 6pcs LPD8806 IC / Meter
- Size: L500cm (5M) x W1.20cm x T0.40cm
- Package: 5 Meters / Reel
- View angle: 120°
- Working Input Voltage: 12VDC
- Output power: 10W / 1 Meter
- Working Temperature: -20° to 50°
- IC chip: LPD8806 256 gray scale
- PCB Background: white
- Waterproof: IP65 waterproof by silicon coating or silicon tube
