Fotek Solid State Relay DC to AC SSR-25DA 25A
Perfectly suited for microcontroller applications where you need to switch larger loads (<10A). Draws 7.4-7.6mA @5VDC in our own tests with an Arduino board.
- Rated Load Current: 25A
- Input Operating Voltage: 3-32VDC
- Min. ON/OFF Voltage: ON > 2.4V, OFF < 1.0V
- Trigger current: 7.5mA @12V
- Control Method: Zero Cross Trigger
- Output Operating Voltage: 24-380VAC
- Voltage Drop: 1.6V / 25°C
- Leakage Current: 3.0mA
- Response Time: ON < 10ms, OF < 10ms
- Dielectric Strength: > 2.5KVAC / 1min
- Isolation Strength: > 50MOhm / 500VDC
- Operating Temperature: -20 - +80°C
- Housing Material: Intensive ABS
Use great caution when working with mains voltage!
